Simplex 4005 Programming Instructions

6-3
Figure 6-2 shows the menu structure of the Front Panel Programmer.
PROGRAMMING MENU EDIT POINT
EDIT CARDS
EDIT SMPL
SYSTEM OPTIONS
ACCESS LEVELS
PASSCODES
RESTORE CFIG (Clear Edit Buffer)
SAVE TO CFIG
Figure 6-2. 4005 Programming Menu Structure
The Edit Point function includes the following:
• Custom Label - 40 Characters
• Point Type
• Modes (valid for RCU/SCU/LCD annunciators and 8-point output only)
− Valid Switch (control) Modes:
SMPL: No mode (point used by SMPL)
ACK: Ack all points (global)
FIREACK: Ack all Fire alarms
SUPVACK: Ack all Supervisory alarms
TBLACK: Ack all Trouble alarms
RESET: Perform a system reset
SILENCE: Perform an alarm silence
TOF: Toggle ON/OFF point
PBT: Push button track point
PBH: Push button hold point
OFF: Turn point OFF
TDE: Toggle disable/enable point
− Valid LED (tracking) modes:
SMPL: No mode (point used by SMPL)
FIRE: Track the Fire alarm state
SUPERVISORY: Track the Supervisory alarm state
TROUBLE: Track the Trouble alarm state
DISABLE:T rack the Disable state
ON: Track the ON state
OFF: Track the OFF state
• List Contents - For list pseudos, the operator can add points to or delete
points from the list.
Continued in next page
Front Panel Programming
Menu Structure
Edit Point
Inputs
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
