Simplex 4005 Programming Instructions

6-12
Table 6-7 lists available Monitor Point types.
Table 6-7. Monitor Point Types
Monitor
Point
Description Monitor
Point
Description
FIRE Fire Monitor Zone FPUMP Fire Pump Monitor
WATER WaterFlow Monitor SFPUMP Supervised Fire Pump
HEAT Heat Detector S2STAGE 2 Stage Monitor
DUCT Duct Detector SO Sprinkler Normally Open
FLAME Flame Detector SC Sprinkler Normally Closed
PULL Manual Pull Station WSO Waterflow/Sprinkler Open
SMOKE Smoke Detector WS: Waterflow/Sprinkler Closed
EMERG Monitor-Fire Emergency SUPV Supervisory Monitor
SFIRE Monitor-Smoke/Fire UTIL Utility Monitor
VFIRE Monitor-Verified Smoke/Pull TROUBLE Trouble Monitor
SPULL Monitor-Smoke/Pull VSMOKE Verified Smoke Detector
VSPULL Verified Smoke/Pull GVMON Generic Verified Zone
GENMON Generator Monitor LATSUPV Supervisory Latching
SGENMON Supervisory Generator STYLEC Monitor-Style C Monitor
Table 6-8 lists available Signal Point types.
Table 6-8. Signal Point Types
Signal Point Description
SSIGNAL: Fire Signal (On Til Silence)
RSIGNAL: Fire Signal (On Til Reset)
TSIGNAL: Trouble (On Til Clear)
BSIGNAL: Trouble (On Til ACK)
SVISUAL: Visual (On Til Silence)
RVISUAL: Visual (On Til Reset)
CODED: Coded Signal
SIGNAL: Signal Circuit
SWATER: WaterFlow (On Til Silence)
RWATER: WaterFlow (On Til Reset)
SUPV: Sprinkler Supervisory Signal
PRIMARY: Elevator Capture (primary
ALTERN: Elevator Capture (alternate)
AHUR: AHU Relay
AHUO: AHU On Relay
AHUF: AHU Off Relay
DHOLDER: Door Holder r
Monitor Point and Signal Point Types
Monitor Point Types
Signal Point Types
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
