Simplex 4005 Programming Instructions

2-4
E.
F.
G.
Figure 2-4. Menu Progression from the Login Accepted Menu to the
Fire, Supervisory, Trouble Menu
5. Press <Enter> to accept the passcode. (Logging in at Level 4 causes a
Simplex Service Mode Trouble. Acknowledge the trouble and continue.)
The display in (E) appears briefly and then (F) appears after the Simplex
Service Mode trouble is acknowledged.
6. Press <Menu> to start Programming (G).
Follow Steps 1 and 2 to log out of the 4005.
1. Press <Next> to scroll through the menus until [3DVVFRGH] is displayed
and then press <Enter>.
2. Press <Next> until [/RJ2XW] is displayed and then press Enter.
The 4005 defaults to Level 1 access.
Basic Things to Know About Programming a 4005, Continued
Default Passcodes (Continued)
Logout
/RJLQLV$FFHSWHG
&XUUHQW$FFHVV/HYHO /HYHO
6LPSOH[6HUYLFH0RGH
7URXEOH3RLQW 7URXEOH 
),5(  683(59,625< 7528%/( 
0HQX >9LHZ3RLQWV@
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
