2-20
To add a Remote Unit Interface (RUI) Card, either a Status Command Unit
(SCU) or a Remote Control Unit (RCU) to the 4005, perform the following
steps:
1. Make sure all jumpers are set correctly and install the card. Refer to the
Field Wiring Diagram 841-990 for more information on wiring the RUI
cards.
After installing the RUI card, apply power to the 4005.
2. Follow Steps 1 through 3 under Editing a Point Label.
3.
P
ress <Ne
xt> or <P
revio
us> to scro
ll through the menus until
[
(GLW&DUG] is displayed (A) and then press <Enter>.
A.
B.
C.
D.
Figure 2-18. Typical Screens Used to Add a
Remote Unit Interface Card
4.
Press <Next> or <P
revious> until [
$GG58,&DUG] is displayed (B) and
then press <Enter>.
The focus brackets ( [ ] ) appear in the Card Address field (C) of the
display.
Note: Annunciator addresses are 1 through 16.
5.
Press <Nex
t> or <Previou
s> to choose t
he Card A
ddress.
6. Press <ö> to move the focus brackets to the Card Type field of the
display (D).
7. Press <Enter> to confirm your selection.
“Configuring the card. . .” is displayed.
Adding a Remote Unit Interface (RUI) Card
Adding a Remote Unit
Interface (RUI) Card
),5( 683(59,625< 7528%/(
3URJUDPPLQJ>(GLW&DUG@
),5( 683(59,625< 7528%/(
(GLW&DUG>$GG58,&DUG@
&DUG >@
&DUG7\SH 6&8&DUG
&DUG
&DUG7\SH >6&8&DUG@
