4-14
In the following example any alarm from floors two and above recalls the
elevator to floor one. An alarm from floor one recalls the elevator to floor
two. Once the elevator is recalled to a floor, a subsequent alarm will not relocate
the elevator to another floor until you reset the system. No SMPL equations are
needed for the operation.
1. Add all monitor zones for floors two and above to the Primary Elevator
Capture Monitors list (31-04).
2. Add all monitor zones for floor one to the Alternate Elevator Capture
Monitors list (31-05).
3. See the Edit Cards, Modify I/O Card Devices section of this publication
to assign the primary and alternate elevator capture relay circuits to AUX.
4. Change the Primary Elevator Capture relay point to a PRIMARY point
type.
5. Change the Alternate Elevator Capture relay point to a ALTERN point
type.
SMPL Language Applications, Continued
Elevator Recall Operation
