Simplex 4005 Programming Instructions

5-20
Auxiliary Relay Points are described in Figures 5-52 through 5-68.
Pt. TYPE: RRELAY Description: Alarm Relay (on until reset)
Operates on General Alarm
Circuit Status LCD Readout (2
nd
line) LED
On Alarm Relay ON
Off Alarm Relay OFF
Alarm Relay CODING
Disabled TBL Alarm Relay TROUBLE T
Off Auto TBL Alarm Relay TROUBLE T
Detailed Description: Used for any relay that must be ON until the system reset
key is pressed.
Figure 5-52. RRELAY Point Type
Pt. TYPE: SRELAY Description: Alarm Relay (on until silence)
Operates on General Alarm
Circuit Status LCD Readout (2
nd
line) LED
On Alarm Relay ON
Off Alarm Relay OFF
Alarm Relay CODING
Disabled TBL Alarm Relay TROUBLE T
Off Auto TBL Alarm Relay TROUBLE T
Detailed Description: Used for any relay that must be ON until the alarm silence
key is pressed.
Figure 5-53. SRELAY Point Type
Pt. TYPE: TRELAY Description: Trouble / Supervisory Relay
(On until clear) Operates on General Alarm
Circuit Status LCD Readout (2
nd
line) LED
On Alarm Relay ON
Off Alarm Relay OFF
Alarm Relay CODING
Disabled TBL Alarm Relay TROUBLE T
Off Auto TBL Alarm Relay TROUBLE T
Detailed Description: Used for any audible or visual device (Trouble or
Supervisory) that must be ON until the condition clears.
Figure 5-54. TRELAY Point Type
Continued on next page
Point Type Messages for Auxiliary Relay Points
Auxiliary Relay Points
