Simplex 4005 Programming Instructions

2-43
The following User Pseudo Points can be added to a List shown in Table 2-7
below.
Digital Pseudos (System Card Address 29)
• Digital Points 29-27 through 29-50 are User Definable as Utility point
types.
Analog Pseudos (System Card Address 30)
• Analog Points 30-05 through 30-25 are User Definable as Analog point
types.
List Pseudo Card (System Card Address 31)
• List Points are shown in Table 2-7.
Table 2-7. Point Numbers and Desciption
Point Number & Description Point Type Purpose
31-1 System Monitors and Manual
Evacuation*
List
Contains all monitor zones and the
manual evacuation pseudo point.
31-2 Waterflow Monitors*
List Contains all waterfiow monitors.
31-3 Sprinkler Monitors*
List Contains all sprinkler monitors.
31-4 Primary Elevator Capture
Monitors
List
User editable list for primary elevator
capture monitor zones.
31-5 Alternate Elevator Capture
Monitors
List
User editable list for alternate elevator
capture monitor zones.
31-6 Points OFF with Silence
List
User editable list for points which turn
OFF with a signal silence operation.
31-7 Points OFF with Reset
List
User editable list for points which turn
OFF with a successful system reset.
31-8 through 31-25 User Definable
List
Open for specific job needs and
requirements.
* Not User Editable
Continued on next page
Operations Involving Lists:
User Pseudo Points
User Pseudo Points
