There are 32 Monitor Points available with the 4005. These are described in
Figures 5-6 through 5-33.
Pt. TYPE: SFIRE Description: Smoke/Fire Combination Zone
Circuit Status LCD Readout (2
nd
line) LED
Normal Fire monitor Zone NORMAL
Limited Fire monitor Zone ALARM A
Open Fire monitor Zone TROUBLE T
Short Fire monitor Zone ALARM A
Disable TBL Fire monitor Zone TROUBLE T
Class A TBL Fire monitor Zone TROUBLE T
Detailed Description: Used when Smoke Detectors and shorting type devices
are used on the same circuit.
Figure 5-6. SFIRE Point Type
Pt. TYPE: VFIRE Description: Verified Smoke/Fire Combination
Circuit Status LCD Readout (2
nd
line) LED
Normal Fire monitor Zone NORMAL
Limited Fire monitor Zone ALARM A
Open Fire monitor Zone TROUBLE T
Short Fire monitor Zone ALARM A
Disable TBL Fire monitor Zone TROUBLE T
Class A TBL Fire monitor Zone TROUBLE T
Detailed Description: Used to activate the alarm verification software for all
smoke detectors connected to this circuit. All shorting devices will cause an
immediate alarm.
Figure 5-7. VFIRE Point Type
Pt. TYPE: SPULL Description: Smoke/Pull Combination Zone
Circuit Status LCD Readout (2
nd
line) LED
Normal Fire monitor Zone NORMAL
Limited Fire monitor Zone ALARM A
Open Fire monitor Zone TROUBLE T
Short Fire monitor Zone ALARM A
Disable TBL Fire monitor Zone TROUBLE T
Class A TBL Fire monitor Zone TROUBLE T
Detailed Description: Used when only Smoke Detectors and Pull Stations are
connected to the circuit.
Figure 5-8. SPULL Point Type
Continued on next page
Point Type Messages for Monitor Points
Monitor Points
