Simplex 4005 Programming Instructions

2-31
To enable or disable the expansion power supply circuit supervision for the
4005, use the following steps:
Important: The Factory Default Setting for the 4005 Expansion Power
supply circuit is ON. When this circuit is turned ON and no
expansion power supply is present in the system, a trouble
occurs.
1. Follow Steps 1 through 3 under Editing a Point Label.
2. Press <Next> or <Previous> to scroll through the menus until [System
Options] is displayed (A) and then press <Enter>.
A.
B.
C.
D.
Figure 2-29. Typical Screens Used to Enable or
Disable the Expansion Power
Supply Circuit Supervision
3. Press <Next> or <Previous> until [
([SDQVLRQ3RZHU] is displayed (B)
and then press <Enter>.
The focus brackets ( [ ] ) appear in the New: field (C) of the display.
4. Press <Next> or <Previous> to choose ON or OFF for the expansion
power circuit and then press <Enter>.
Note: When initially setting a value for a System Option, all values in
the ‘New’: field will reflect the ‘Current:’ field's setting.
5. Press <Enter> to confirm your selection or <Exit/Clear> to cancel (D).
“Option is updated” is displayed when selecting Enter.
Expansion Power Supply Circuit Supervision
Enabling or Disabling the
Expansion Power Supply
Circuit Supervision
),5(  683(59,625< 7528%/( 
3URJUDPPLQJ>6\VWHP2SWLRQV@
),5(  683(59,625< 7528%/( 
6\VWHP2SWLRQV>([SDQVLRQ3RZHU@
([SDQVLRQ3RZHU
1HZ>21@  &XUUHQW21
3UHVV(17(5WRFRQILUP(;,7WRFDQFHO
1HZ>2))@  &XUUHQW21
