3-18
When using the input condition qualifier ANY, a statement is true when the
specified number of points from Field B equals the number of points in the List
identified in Field D that are in the condition specified by Field C. The choices
for Fields B, C, and D are as follows:
• Field B – Point number value 001 to 255
• Field C – Conditions FIRE ACK, SUP ACK, TBL ACK, FIRE, SUP,
TBL, ON IN, ON CODE, PHY NRM, PHY ABN, PHY SHR, FIRE DET,
DISABLE, MAN
• Field D – List Points 22-01 through 22-25
Field A Field B Field C Field D
[$1<] [] [),5($&.] []
Figure 3-28. An Example Using the Input Condition Qualifier ANY
Example: When any one (1) point’s condition in the List 22-01 is FIRE ACK,
then execute the output.
Note: When choosing the ALL condition qualifier, there are only three
fields open for programming.
When using the input condition qualifier ALL, a statement is true when all points
specified in Field C are in the condition specified in Field B. The choices for
Fields B and C are as follows:
• Field B Conditions FIRE ACK, SUP ACK, TBL ACK, FIRE, SUP,
TBL, ON IN, ON CODE, PHY NRM, PHY ABN, PHY SHR, FIRE DET,
DISABLE, MAN
• Field C List Points 22-01 through 22-25
Field A Field B Field C Field D
[$//] [),5($&.] [] []
Figure 3-29. An Example Using the ALL Condition Qualifier
Example: When all points in List 22-01 are in the condition of FIRE ACK, then
execute the output.
Continued on next page
Second Stage Fields, Continued
Using the ANY Qualifier
Using the ALL Qualifier
Two-stage Input
Condition
Specifier
Condition
List Point
SECOND STAGE
FIELDS
Two-stage Input
Condition
Specifier
Point Number
Value
Condition
List Point
SECOND STAGE
FIELDS
