Simplex 4005 Programming Instructions

2-12
To Edit the Point Type of a point, use the following steps:
1. Follow Steps 1 through 5 under Edit Label.
2. Press <Next> or <Previous> to scroll through the points until the point
you wish to edit is displayed (A) and then press <Function>.
A.
B.
C.
D.
Figure 2-11. Typical Screens Used to Edit Point Types
3. Press <Next> or <Previous> to scroll through the menus until
[
(GLW3RLQW7\SH] is displayed (B) and then press <Enter>.
4. Press <Next> or <Previous> to scroll through the point types until the
desired type is displayed (C) and then press <Enter> (refer to the
Programming Sheets in Appendix A for a complete list of point types).
5. A Confirmation screen appears (D) allowing you to make or abandon the
changes. Press <Enter> to confirm your choice, or <Exit/Clear> to
abandon your changes.
The 4005 informs you when the Operation is Complete.
Editing Point Types
Editing Point Types
,2&DUG,QSXW
0RQLWRU=RQH  
,2&DUG,QSXW
&RQWURO>(GLW3RLQW/DEHO@
,2&DUG,QSXW
>),5()LUH0RQLWRU=RQH@
3UHVV(17(5WR&RQILUP(;,7WRFDQFHO
>),5()LUH0RQLWRU=RQH@
