2-21
To delete a Remote Unit Interface (RUI) Card, either a Status Command Unit
(SCU) or a Remote Control Unit (RCU) from the 4005, perform the following
steps:
Note: Deleting a card from the 4005 also removes any modes or SMPL
equations associated with that card.
1. Follow Steps 1 through 3 under Editing a Point Label.
2. Press <Next> or <Previous> to scroll through the menus until
[
(GLW&DUG] is displayed (A) and then press <Enter>.
A.
B.
C.
D.
Figure 2-19. Typical Screens Used to Delete a
Remote Unit Interface Card
3. Press <Next> or <Previous> until [
'HOHWH58,&DUG] is displayed (B)
and then press <Enter>.
The focus brackets ( [ ] ) appear in the Card Address field (C) of the
display.
4. Press <Next> or <Previous> to choose the Card to delete and then press
<Enter>.
5. Press <Enter> to confirm your selection.
Removing the card. . . is displayed.
6. After deleting a card, the 4005 displays the next available card for
deletion. To avoid deleting the next card, press <Exit/Clear>.
Deleting a Remote Unit Interface (RUI) Card
Deleting a Remote Unit
Interface (RUI) Card
),5(  683(59,625< 7528%/( 
3URJUDPPLQJ>(GLW&DUG@
),5(  683(59,625< 7528%/( 
(GLW&DUG>'HOHWH58,&DUG@
&DUG >@
&DUG7\SH 6&8&DUG
&DUG 
&DUG7\SH >6&8&DUG@
