Follow Steps 1 through 4 to access the Custom Control program editor.
1. Log in at the appropriate level.
2. Press <Menu>.
3.
Press <P
revious> or <Next> until [
3URJUDPPLQJ] (A) is displayed and then press <Enter>.
4.
Press <P
revious> or <Next> until [
&XVWRP&RQWURO] (B) is displayed and then press <Enter>.
A.
B.
Figure 3-1. Screens Used to Start Custom Control Programming
Using <N
ext> and
<P
revio
us>, you ca
n scro
ll thro
ugh all the
existing e
quatio
ns
of the Custom Control program.
Note: All insertions are done above the current location.
If you wish to create a new equation before the first equation in the program,
press <Next> to scroll to Equation 1 and then select Insert. When the new
equation has been created and saved it will become Equation 1 and all other
equations are incremented by 1.
If you wish to add a new equation to the end of the program, press <Next> or
<Previous> until ** End of Program ** is displayed on the screen. Select Insert
from the menu to create a new equation at the end of the current equation list
with the number of the last equation plus 1.
Note: Selecting Insert does NOT change the current focus. That is, if
you insert at the end of program marker when the action is
completed, the current focus is still at the ** End of Program **
marker. This facilitates sequentially entering a program when
none is present or adding a sequence of equations within the
existing program.
Continued on next page
Custom Control, Continued
To Start Custom Control
Programming
Custom Control Menu
Navigation
),5( 683(59,625< 7528%/(
0HQX>3URJUDPPLQJ@
),5( 683(59,625< 7528%/(
3URJUDPPLQJ>&XVWRP&RQWURO@
