5-1
The Point Type determines:
• What words will be displayed on the bottom line of the LCD display
• Which LED will be illuminated (Status LEDs)
• The software operation of the panel
• May determine the field wiring arrangement
The charts shown in this chapter have five major sections as described in
Figure 5-1.
Pt. TYPE: FIRE Description: Generic Fire Alarm
Circuit Status LCD Readout (2
nd
line) LED
Normal Fire monitor Zone NORMAL
Limited Fire monitor Zone ALARM A
Open Fire monitor Zone TROUBLE T
Short Fire monitor Zone ALARM A
Disable TBL Fire monitor Zone TROUBLE T
Class A TBL Fire monitor Zone TROUBLE T
Detailed Description: Additional information about a circuit can always be
obtained. For instance, if you interrogated the panel about a monitor zone with
a point type of FIRE, and the zone is normal, the display…
Figure 5-1. Point Type Chart sections
A typical LCD Panel display is shown in Figure 5-2.
Figure 5-2. Typical LCD Panel display
Additional information about the Point can be displayed by pressing the <ö>
key. Figure 5-3 shows this additional information.
Figure 5-3. Additional Information after <ö> key press
Again, additional information about the Point can be displayed by pressing the
<ö> key. Figure 5-4 shows this further information.
Figure 5-4. Additional Information after 2
nd
<ö> key press
Continued on next page
Chapter 5
Point Type Charts
Introduction
Displaying information on the
LCD Panel
Point Type and
Description
Circuit Status
Column
LCD Readout
(exact wording)
Status reported
(LED indication)
Detailed description
of the Point Type
5RRP7UDLQLQJ&HQWHU %XLOGLQJ
)LUH0RQLWRU=RQH 1250$/
'HYLFH
021% &DUG
3RLQW
)LUH0RQLWRU=RQH 1250$/
3K\VLFDO6WDWXV
1250$/ (1$%/('
&ODVV$
1250$/ 7DOO\
