Simplex 4005 Programming Instructions

6-15
Table 6-12 describes the Points associated with the CPU Card (System Address 0).
Table 6-12. CPU Card (System Address 0)
Point Number: Description Device Type Point Type Purpose
1: City Circuit 1/DACT Monitor Generic Input Utility Detect abnormal condition on city
circuit 1 or DACT
2: City Circuit 2 Monitor Generic Input Utility Detect abnormal condition on city
circuit 2
3: External RUI Monitor Generic Input Utility Monitor RUI comm channel for
short
4: Channel 1 Output Generic Output Control Annunciates system fire condition
5: Channel 2 Output Generic Output Control Annunciates system priority 2
conditions
6: Channel 3 Output Generic Output Control Annunciates system supervisory
conditions
7: Channel 4 Output Generic Output Control Annunciates system trouble
conditions
8: AC Failure Output Generic Output Control Annunciates system AC fail
conditions
9: 4-wire Detector Power Generic Output Control Supplies 4-wire power to
detectors
10: LCD Backlight Control Generic Output Control Turns on/off LCD backlight
11: Front Panel Piezo Control Generic Output Piezo Controls front panel piezo
12: Fire Alarm LED Generic Output Led Controls front panel fire alarm led
13: Supervisory LED Generic Output Led Controls front panel supervisory
led
14: Trouble LED Generic Output Led Controls front panel trouble led
15: Alarm Silence LED Generic Output Led Controls front panel alarm
silenced led
16: AC Power LED Generic Output Led Controls front panel AC power led
17: RUI Disconnect Control Generic Output Control Isolates internal from external RUI
Continued on next page
Reference Information
CPU Card
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
