When using the input condition qualifier FIRE ACK (Fire Acknowledge), a
statement is true when the point indicated in Field 4 is activated. Field 4
Choices for the FIRE ACK qualifier are:
• System Card Points
• Digital Pseudo Points
Note: The statement holds true until the point indicated in Field 4 is
Acknowledged. The Output operator used for the example below
is TRACK.
Field 1 Field 2 Field 3 Field 4
[] [] [),5($&.] []
Field 1 Field 2 Field 3 Field 4
[] [] [),5($&.] []
Figure 3-20. An Example Where the First and the Second Statement
Both Contain the Condition FIRE ACK
Example: The condition of 03-01 is FIRE ACK. The input of the equation
remains true until the point indicated in Field 4 is acknowledged
from the FACP. The same holds true for 03-02.
When using the input condition qualifier SUPV (Supervisory), a statement is true
when the point indicated in Field 4 is activated. Field 4 Choices for the SUPV
qualifier are:
• System Card Points
• Digital Pseudo Points
Note: The statement holds true until the point indicated in Field 4 clears.
Field 1 Field 2 Field 3 Field 4
[] [] [6839] []
Figure 3-21. An Example That Contains the Condition SUPV
Example: The condition of 03-01 is SUPV. The input of the equation remains
true until the point indicated in Field 4 is cleared.
Continued on next page
Input Field 3 and Input Field 4, Continued
Using the FIRE ACK Qualifier
Using the SUPV Qualifier
FIRST STATEMENT
SECOND STATEMENT
FIRST STATEMENT
