4-12
In the following example there is a 4602 SCU Serial Annunciator in the entry
way of a building. The fire department would like the smoke detectors pull
stations, and water flow devices alarm status to annunciate by floor. There
are three floors and its a general alarm system.
1. Create a user list that includes all monitor zones for each floor (see the
Lists, Add Points to a List section of this publication).
2. Label the user list for each floor "1st Floor Alarm, 2nd Floor Alarm,
and 3rd Floor Alarm respectively (see the Edit Points, Edit Point Label
section of this publication).
3. Change the labels assigned to the RCU LEDs that are used to annunciate
the floor in alarm to "Fire First Floor, Fire Second Floor, and Fire
Third Floor respectively.
4. Add the following SMPL equations (see the To Start SMPL Programming
section of this publication).
Zone Grouping - Equation 1
Equation Point Label Point Type
$1<),5( VW)ORRU$ODUP
(QGRI,QSXW
+2/'2135, )LUHVW)ORRU
(QGRI2XWSXW
Zone Grouping - Equation 2
Equation Point Label Point Type
$1<),5( QG)ORRU$ODUP
(QGRI,QSXW
+2/'2135, )LUHQG)ORRU
(QGRI2XWSXW
Zone Grouping - Equation 3
Equation Point Label Point Type
$1<),5( UG)ORRU$ODUP
(QGRI,QSXW
+2/'2135, )LUHUG)ORRU
(QGRI2XWSXW
Continued on next page
