Simplex 4005 Programming Instructions

6-16
Addresses 1 through 16 are reserved for RCU, SCU, and RCU/SCU graphic
drive Annunciators. Address 17 is reserved for a test RCU.
ZONE 1
ZONE 2
ZONE 3
ZONE 4
ZONE 5
ZONE 6
ZONE 7
ZONE 8
P
W
R
T
B
L
TROUBLE
SILENCE
SYSTEM
RESET
ALARM
SILENCE
MANUAL
EVAC
ENABLE
Figure 6-3. RCU
ZONE 1
ZONE 2
ZONE 3
ZONE 4
ZONE 5
ZONE 6
ZONE 7
ZONE 8
ZONE 9
ZONE10
ZONE 11
ZONE 12
ZONE 13
ZONE 14
ZONE 15
ZONE 16
Figure 6-4. SCU
Continued on next page
Reference Information, Continued
RCU/SCU Addresses
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
