Simplex 4005 Programming Instructions

6-18
Table 6-13 describes the Points associated with the Power Supply Card (System
Address 28).
Table 6-13. Power Supply Card (System Address 28)
Point Number: Description Device Type Point Type Purpose
1: Battery Voltage Monitor Generic Input Utility Low battery monitor input
2: Battery Depleted Monitor Generic Input Utility Depleted battery monitor input
3: Battery Missing Monitor Generic Input Trouble Missing battery monitor input
4: Battery Charge Current Generic Input Utility Battery charger current
5: Battery Supervision Generic Input Utility Battery supervision monitor
6: Earth/Ground Fault Generic Input Trouble Earth/Ground fault monitor
7: Main Supply Overcurrent Generic Input Trouble Main supply overcurrent monitor
8: AC Failure Monitor Generic Input Trouble AC failure monitor
9: Charger Failure Generic Input Trouble Battery Charger Failure
10: Right Backplane Overcurrent Generic Input Trouble Right backplane overcurrent
monitor
11: Left Backplane Overcurrent Generic Input Trouble Left backplane overcurrent
monitor
12: Main Power Tap Control Generic Output Control Main power tap control (on/off)
13: Battery Charger State Generic Output Control Battery charger state (on/off)
14: Battery Charger Rate Generic Output Control Battery charger rate (high/trickle)
15: Expansion Power Tap Control Generic Output Control Expansion power tap control
(on/off)
Continued on next page
Reference Information, Continued
Power Supply Card
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
