Simplex 4005 Programming Instructions

3-14
When using the input condition qualifier SUPV ACK (Supervisory
Acknowledge), a statement is true when the point indicated in Field 4 is
activated. Field 4 choices for the SUPV ACK qualifier are:
• System Card Points
• Digital Pseudo Points
Note: The statement holds true until the point indicated in Field 4 is
Acknowledged.
Field 1 Field 2 Field 3 Field 4
[] [] [6839$&.] []
Figure 3-22. An Example That Contains the Condition SUPV ACK
Example: The condition of 03-01 is SUPV ACK. The input of the equation
remains true until the point indicated in Field 4 is acknowledged
from the FACP.
When using the input condition qualifier TBL (Trouble), a statement is true
when the point indicated in Field 4 is in trouble. Field 4 choices for the TBL
qualifier are:
• CPU Card Points
• System Card Points
• Power Supply Points
• Digital Pseudo Points
Note: The statement holds true until the point indicated in Field 4 not in
trouble.
Field 1 Field 2 Field 3 Field 4
[] [] [7%/] []
Figure 3-23. An Example That Contains the Condition TBL
Example: The condition of 03-01 is TBL. The input of the equation remains
true until the point indicated in Field 4 is not in trouble.
Continued on next page
Input Field 3 and Input Field 4, Continued
Using the SUPV ACK Qualifier
Using the TBL Qualifier
FIRST STATEMENT
FIRST STATEMENT
