5-13
Signal Points are described in Figures 5-34 through 5-51.
Pt. TYPE: TSIGNAL Description: Trouble / Supervisory Signal (until
clear)
Circuit Status LCD Readout (2
nd
line) LED
Normal Trouble Signal ON
Normal Trouble Signal OFF
Normal Trouble Signal CODING
Open Trouble Signal TROUBLE T
Short Trouble Signal TROUBLE T
Disable TBL Trouble Signal TROUBLE T
Off Auto TBL Trouble Signal TROUBLE T
Detailed Description: Used when an audible signal should activate on any
system Trouble or Supervisory condition and remain ON until the Trouble or
Supervisory condition as cleared.
Figure 5-34. TSIGNAL Point Type
Pt. TYPE: BSIGNAL Description: Trouble / Supervisory Signal (until
acknowledge)
Circuit Status LCD Readout (2
nd
line) LED
Normal Trouble Signal ON
Normal Trouble Signal OFF
Normal Trouble Signal CODING
Open Trouble Signal TROUBLE T
Short Trouble Signal TROUBLE T
Disable TBL Trouble Signal TROUBLE T
Off Auto TBL Trouble Signal TROUBLE T
Detailed Description: Used when an audible signal should activate on any
Trouble or Supervisory condition and remain ON only until the condition has
been acknowledged.
Figure 5-35. BSIGNAL Point Type
Continued on next page
Point Type Messages for Signal Points
Signal Points
