Simplex 4005 Programming Instructions

5-12
Pt. TYPE: TROUBLE Description: Trouble Monitor (no alarm)
Circuit Status LCD Readout (2
nd
line) LED
Normal Trouble Monitor NORMAL
Limited Trouble Monitor TROUBLE T
Open Trouble Monitor TROUBLE T
Short Trouble Monitor TROUBLE T
Disable TBL Trouble Monitor TROUBLE T
Class A TBL Trouble Monitor TROUBLE T
Detailed Description: Used for monitoring only.
Figure 5-32. TROUBLE Point Type
Pt. TYPE: STYLEC Description: Monitor-Style C Monitor
Circuit Status LCD Readout (2
nd
line) LED
Normal Monitor Zone NORMAL
Limited Monitor Zone ALARM A
Open Monitor Zone TROUBLE T
Short Monitor Zone TROUBLE T
Disable TBL Monitor Zone TROUBLE T
Class A TBL Monitor Zone TROUBLE T
Detailed Description: Used when only current limited devices are connected to
the circuit. A short circuit is reported as a TROUBLE.
Figure 5-33. STYLEC Point Type
Point Type Messages for Monitor Points, Continued
Monitor Points (continued)
