Simplex 4005 Programming Instructions

6-13
Use Table 6-9 to record your Notification Appliance Circuit (NAC)/Relay
points.
Table 6-9. NAC/Relay Circuits and Descriptions
NAC/Auxiliary Relay Type — 34 NACs/Relays Maximum
RELAY DESCRIPTION RELAY DESCRIPTION
1 18
2 19
3 20
4 21
5 22
6 23
7 24
8 25
9 26
10 27
11 28
12 29
13 30
14 31
15 32
16 33
17 34
Table 6-10 lists available Relay Point types.
Table 6-10. Relay Point Types
Relay Point Description
RELAY Auxiliary Relay
PRIMARY Elevator Capture (Primary)
ALTERN Elevator Capture (Alternate)
AHUR AHU Relay
AHUO AHU On Relay
AHUF AHU Off Relay
SRELAY Fire Relay (On Til Silence)
RRELAY Fire Relay (On Til Ack)
TRELAY Trouble Relay (On Til Clear)
BRELAY Trouble Relay (On Til Ack)
DHOLDER Door Holder
SVISUAL Visual (On Til Silence)
RVISUAL Visual (On Til Reset)
CODED Coded Relay
WaterFlow Waterflow Relay
SUPV Supervisory Relay
NAC/Relay Circuits
Recording your System’s
NAC/Relay Points
Relay Point Types
