1-2
The following manuals contain information about the 4005:
Publication Title Part #
4005 Fire Alarm Installation/Operating Instructions
Rev. A
574-068
4005 Operating Instructions Following an
Alarm/Supervisory/Trouble Condition
. . . Ed 8 95
574-069
4005 Fire Alarm I/O Cards – Installation Instructions
Ed 3 96
574-070
4005 Fire Alarm City Circuit Card – Installation
Instructions .
. . Rev. B
574-071
4005 Fire Alarm Expansion Power Supply & Power
Distribution Boards – Installation Instructions .
. . Rev. A
574-072
4005 Fire Alarm PC Interface Operating Instructions
Rev. A
574-328
4005 Fire Alarm Programming Sheets FA4-41-655
4005 Fire Alarm Pocket Training Reference FA4-91-654
The 4005 is a microprocessor-based, battery-backed, electrically-supervised fire
alarm system capable of supporting from 8 to 40 circuits. These circuits, either
initiating device circuits (IDC) or notification appliance circuits (NAC), are
added to the system in blocks of four. In addition, the 4005 can automatically
control supplementary equipment such as fire doors and fans during a fire
condition using NACs converted to auxiliary relay outputs.
The 4005 provides audible and visible indications during trouble, supervisory, or
alarm (fire) conditions. Should any of these conditions occur, the system
activates the applicable notification appliance(s), LEDs, and the panel tone-alert.
The indications continue until someone appropriately acknowledges the
condition.
