Simplex 4005 Programming Instructions

6-17
I/O Card addresses are 18 through 27.
18
18
19
19
20
20
21
21
22
22
27
27
26
26
25
25
24
24
23
23
Figure 6-5. I/O Card Address/Locations
Reference Information, Continued
Input/Output Card Addresses
Card Address 18
(Slot # 1)
Card Address 19
(Slot # 2)
Card Address 20
(Slot # 3)
Card Address 21
(Slot # 4)
Card Address 22
(Slot # 5)
Card Address 27
(Slot # 10)
Card Address 26
(Slot # 9)
Card Address 25
(Slot # 8)
Card Address 24
(Slot # 7)
Card Address 23
(Slot # 6)
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
