Simplex 4005 Programming Instructions

4-1
This chapter discusses some common Simplex Multi-functional Programming
Language (SMPL) applications.
In the following example any activated initiating device (e.g., smoke detectors
and pull stations) on the first floor energizes the signals (e.g., horns) on the
first floor. Initiating devices on the second floor energizes the signals on the
second floor, and so on. Signals will March Time until silenced by the alarm
silence key.
1) Edit a NAC/Relay card and assign NAC circuits as Signal points (see the
Edit Card, Modify I/O Card Devices section of this publication).
2) Change the point type (see the Edit Points, Edit Point Type section of this
publication).
3) Change the custom label of the point (see the Edit Points, Edit Point
Label section of this publication).
4) Add the signal to the "Control Points, OFF with Silence" List 31-06 (see
the Lists, Add Points to a List section of this publication).
5) Add the following SMPL equations (see the To Start SMPL Programming
section of this publication):
Selective Signals by Floor - Equation 1
Equation Point Label Point Type
),5('(7 VW)ORRU(DVW:LQJ 
25),5('(7 VW)ORRU(DVW:LQJ
(QGRI,QSXW
0$5&+3UL VW)ORRU(DVW:LQJ 6LJQDO
(QGRI2XWSXW
Selective Signals by Floor - Equation 2
Equation Point Label Point Type
),5('(7 QG)ORRU(DVW:LQJ
25),5('(7 QG)ORRU(DVW:LQJ
(QGRI,QSXW
0$5&+3UL QG)ORRU(DVW:LQJ 6LJQDO
(QGRI2XWSXW
Continued on next page
Chapter 4
Common Simplex Multi-functional Programming
Language (SMPL) Applications
Introduction
Selective Signals by Floor
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
