To Clear a Custom Label of a point, use the following steps:
1. Follow Steps 1 through 5 under Editing a Point Label.
2. Press <Next> or <Previous> to scroll through the points until the point
you wish to clear is displayed (A) and then press <Function>.
A.
B.
C.
Figure 2-10. Typical Screens Used to Change a Point Label
3. Press <Next> or <Previous> to scroll through the menus until
[
&OHDU3RLQW/DEHO] is displayed (B) and then press <Enter>.
Important: Once <Enter> is pressed, the label clears (C). The 4005 is
now in the Edit Label mode. When a label is accidentally
cleared, press <Exit/Clear> and re-enter the Clear Point
Label menu to clear the correct label.
Clearing a Point Label
Clearing a Point Label
F
,2&DUG,QSXW
0RQLWRU=RQH  
,2&DUG,QSXW
&RQWURO>&OHDU3RLQW/DEHO@
³
0RQLWRU=RQH
