Simplex 4005 Programming Instructions

2-26
The Door Drop Alarm is a specified time (0-60 secs.) doors are held open after
an alarm. To set the Door Drop Alarm Timer in seconds for the 4005, use the
following steps:
1. Follow Steps 1 through 3 under Editing a Point Label.
2. Press <Next> or <Previous> to scroll through the menus until
[
6\VWHP2SWLRQV] is displayed (A) and then press <Enter>.
A.
B.
C.
D.
Figure 2-24. Typical Screens Used to Set the
Door Drop Alarm
3. Press <Next> or <Previous> until [
'RRU'URS$ODUP] is displayed (B)
and then press <Enter>.
The focus brackets ( [ ] ) appear in the New: field (C) of the display.
4. Press <Next> or <Previous> to choose the duration (1-60 seconds) for the
door holder alarm drop timer and then press <Enter>.
Note: When initially setting a value for a System Option, all values in
the ‘New:’ field will reflect the ‘Current:’ field's setting. A value of
00 is considered a disabled state of that System Option (for
example, 00 Secs means that the Door Holder Alarm Drop Timer
is not active).
5. Press <Enter> to confirm your selection or Exit to cancel (D).
“Option is updated” is displayed when selecting Enter.
Door Drop Alarm
Setting the Door Drop Alarm
),5(  683(59,625< 7528%/( 
3URJUDPPLQJ>6\VWHP2SWLRQV@
),5(  683(59,625< 7528%/( 
6\VWHP2SWLRQV>'RRU'URS$ODUP@
'RRU+ROGHU²$ODUP'URS7LPHU
1HZ>@  &XUUHQW6HFV
3UHVV(17(5WRFRQILUP(;,7WRFDQFHO
1HZ>@  &XUUHQW6HFV
