Simplex 4005 - Using the TBL ACK Qualifier; Using the ON;CODE and off Qualifiers

3-15
When using the input condition qualifier TBL ACK (Trouble Acknowledge), a
statement is true when the point indicated in Field 4 is in trouble. Field 4
choices for the TBL ACK qualifier are:
]
• CPU Card Points
• System Card Points
• Power Supply Points
• Digital Pseudo Points
Note: The statement holds true until the point indicated in Field 4 (in
trouble) is Acknowledged.
Field 1 Field 2 Field 3 Field 4
[] [] [7%/$&.] []
Figure 3-24. An Example That Contains the Condition TBL ACK
Example: The condition of 03-01 is TBL ACK. The input of the equation
remains true until the point indicated in Field 4 is acknowledged
from the FACP.
When using the input condition qualifier ON/CODE (On Coding), a statement is
true when the point indicated in Field 4 is On or Coding. Field 4 choices for the
ON/CODE qualifier are:
• CPU Card Points
• System Card Points
• Power Supply Points
• Digital Pseudo Points
• Analog Pseudo Points
Note: The statement holds true until the point indicated in Field 4 is OFF.
Field 1 Field 2 Field 3 Field 4
[] [] [21&2'(] []
Figure 3-25. An Example That Contains the Condition Qualifier
ON/CODE
Example: The condition of 03-01 is ON/CODE. The input of the equation
remains true until the point indicated in Field 4 is OFF.
Continued on next page
Input Field 3 and Input Field 4, Continued
Using the TBL ACK Qualifier
Using the ON/CODE and OFF
Qualifiers
FIRST STATEMENT
FIRST STATEMENT
