When using the input condition qualifier OFF, a statement is true when the point
indicated in Field 4 is OFF. Field 4 choices for the OFF qualifier are:
• CPU Card Points
• System Card Points
• Power Supply Points
• Digital Pseudo Points
• Analog Pseudo Points
Note: The statement holds true until the point indicated in Field 4 is ON
or Coding.
Field 1 Field 2 Field 3 Field 4
[] [] [2))] []
Figure 3-26. An Example That Contains the Condition OFF
Example: The condition of 03-01 is OFF. The input of the equation remains
true until the point indicated in Field 4 is ON or Coding.
Input Field 3 and Input Field 4, Continued
Using the ON/CODE and OFF
Qualifiers (Continued)
FIRST STATEMENT
