1-1
This publication shows how to use the menu-driven Front Panel Programming
feature of the 4005 Fire Alarm. All control of the 4005 is allowed through the
front panel via menus and the keypad.
Note: When a membrane panel key is referenced in this manual, it is
normally shown between angle brackets. Examples are
<Menu> and <System Reset>.
Chapter 2 shows the basic programming involved with factory-configured
operation of the 4005. The 4005 base panel is configured (and shipped) as a
general alarm system. A number of menu selectable options are provided to
further enhance the 4005 operation.
The 4005 has resident editing capability. Once the programming mode is
selected, the 4005’s LCD display and keypad become the indicator and controls
of the resident editor (programmer).
Chapter 3 shows how to use the Simplex Multi-functional Programming
Language (SMPL) to program custom functions into the 4005 when more
sophisticated operations are required. The SMPL option can be used to
customize the operation of an Output, while the rest of the system continues to
operate as a general alarm system. The SMPL programming provides many
more features and applications which are discussed in this manual.
Chapter 4 contains a number of SMPL applications with examples of equations
used for various control and signaling functions.
Chapter 5 contains Point Type Charts which list exact LCD displays and system
status corresponding to each type of Point in the 4005 system.
Chapter 6 contains Programming Guides and Reference Information to assist you
in planning and documenting the programming steps you take. This chapter also
provides information about System Addresses, Point and Device Types, and
Point descriptions.
Important: The 4005 system continues to operate as a fire alarm
system during programming operations
Continued on next page
Chapter 1
System Overview
Introduction
