2-41
A Cold Start of the 4005 clears Historical Logs, Time/Date, and causes a Cold
Start Trouble that clears upon acknowledgment. To execute a cold start perform
the following steps and refer to Figure 2-40.
1. Log in to the 4005.
2. Press <Menu> (A).
A.
B.
C.
Figure 2-40. Typical Screens Used to Execute
a Cold Start
3. Press <Next> or <Previous> to scroll through the menus until
[
&ROG6WDUW] is displayed (B) and then press <Enter>.
4. Press<Enter> to enable a cold start on the next press of the CPU Warm
Start button located on the CPU board below the main display (see
Figure 2-41) or press <Exit/Clear> to cancel (C).
Press CPU Reset to Perform Cold Start is displayed.
Continued on next page
Cold Start
Executing a Cold Start
),5(  683(59,625< 7528%/( 
0HQX >9LHZ3RLQW@
),5(  683(59,625< 7528%/( 
0HQX>&ROG6WDUW@
3UHVV(17(5WR(QDEOH&ROG6WDUW
3UHVV(;,7WRFDQFHO
