Simplex 4005 Programming Instructions

5-4
Pt. TYPE: VSPULL Description: Verified Smoke/Pull Combination
Circuit Status LCD Readout (2
nd
line) LED
Normal Fire monitor Zone NORMAL
Limited Fire monitor Zone ALARM A
Open Fire monitor Zone TROUBLE T
Short Fire monitor Zone ALARM A
Disable TBL Fire monitor Zone TROUBLE T
Class A TBL Fire monitor Zone TROUBLE T
Detailed Description: Used when only Smoke Detectors and Pull Stations are
connected to the circuit.
Figure 5-9. VSPULL Point Type
Pt. TYPE: VSMOKE Description: Verified Smoke Detector Only
Circuit Status LCD Readout (2
nd
line) LED
Normal Fire monitor Zone NORMAL
Limited Fire monitor Zone ALARM A
Open Fire monitor Zone TROUBLE T
Short Fire monitor Zone ALARM A
Disable TBL Fire monitor Zone TROUBLE T
Class A TBL Fire monitor Zone TROUBLE T
Detailed Description: Used when only Smoke Detectors that must be verified
are connected to the circuit.
Figure 5-10. VSMOKE Point Type
Pt. TYPE: GVMON Description: Generic Verified Monitor
Circuit Status LCD Readout (2
nd
line) LED
Normal Fire monitor Zone NORMAL
Limited Fire monitor Zone ALARM A
Open Fire monitor Zone TROUBLE T
Short Fire monitor Zone ALARM A
Disable TBL Fire monitor Zone TROUBLE T
Class A TBL Fire monitor Zone TROUBLE T
Detailed Description: Used when abnormal condition of the circuit must be
verified.
Figure 5-11. GVMON Point Type
Continued on next page
Point Type Messages for Monitor Points, Continued
Monitor Points (continued)
