5-5
Pt. TYPE: FIRE Description: Generic Fire Alarm
Circuit Status LCD Readout (2
nd
line) LED
Normal Fire monitor Zone NORMAL
Limited Fire monitor Zone ALARM A
Open Fire monitor Zone TROUBLE T
Short Fire monitor Zone ALARM A
Disable TBL Fire monitor Zone TROUBLE T
Class A TBL Fire monitor Zone TROUBLE T
Detailed Description: Used for all fire alarm zones where more than one type of
device may be connected. For example, smokes, pulls, waterflows, and heats
are all connected to the same circuit. Shorts and current limited activate
alarms.
Figure 5-12. FIRE Point Type
Pt. TYPE: WATER Description: WaterFlow Monitor
Circuit Status LCD Readout (2
nd
line) LED
Normal WaterFlow Monitor NORMAL
Limited WaterFlow Monitor ALARM A
Open WaterFlow Monitor TROUBLE T
Short WaterFlow Monitor ALARM A
Disable TBL WaterFlow Monitor TROUBLE T
Class A TBL WaterFlow Monitor TROUBLE T
Detailed Description: Used when only waterflow monitors are connected to the
circuit. Shorts and current limited are treated the same (activate alarms).
Figure 5-13. WATER Point Type
Pt. TYPE: HEAT Description: Heat Detector
Circuit Status LCD Readout (2
nd
line) LED
Normal Heat Detector NORMAL
Limited Heat Detector ALARM A
Open Heat Detector TROUBLE T
Short Heat Detector ALARM A
Disable TBL Heat Detector TROUBLE T
Class A TBL Heat Detector TROUBLE T
Detailed Description: Used when only Heat Detectors are connected to the
circuit.
Figure 5-14. HEAT Point Type
Continued on next page
Point Type Messages for Monitor Points, Continued
Monitor Points (continued)
