Simplex 4005 Programming Instructions

5-6
Pt. TYPE: DUCT Description: Duct Detector
Circuit Status LCD Readout (2
nd
line) LED
Normal Duct Detector NORMAL
Limited Duct Detector ALARM A
Open Duct Detector TROUBLE T
Short Duct Detector ALARM A
Disable TBL Duct Detector TROUBLE T
Class A TBL Duct Detector TROUBLE T
Detailed Description: Used when only Duct Detectors are connected to the
circuit.
Figure 5-15. DUCT Point Type
Pt. TYPE: FLAME Description: Flame Detector
Circuit Status LCD Readout (2
nd
line) LED
Normal Flame Detector NORMAL
Limited Flame Detector ALARM A
Open Flame Detector TROUBLE T
Short Flame Detector ALARM A
Disable TBL Flame Detector TROUBLE T
Class A TBL Flame Detector TROUBLE T
Detailed Description: Used when only Flame Detectors are connected to the
circuit.
Figure 5-16. FLAME Point Type
Pt. TYPE: PULL Description: Pull (manual) Station
Circuit Status LCD Readout (2
nd
line) LED
Normal Manual Pull Station NORMAL
Limited Manual Pull Station ALARM A
Open Manual Pull Station TROUBLE T
Short Manual Pull Station ALARM A
Disable TBL Manual Pull Station TROUBLE T
Class A TBL Manual Pull Station TROUBLE T
Detailed Description: Used when only Pull Stations are connected to the circuit.
Figure 5-17. PULL Point Type
Continued on next page
Point Type Messages for Monitor Points, Continued
Monitor Points (continued)
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
