5-7
Pt. TYPE: SMOKE Description: Smoke Detector
Circuit Status LCD Readout (2
nd
line) LED
Normal Smoke Detector NORMAL
Limited Smoke Detector ALARM A
Open Smoke Detector TROUBLE T
Short Smoke Detector ALARM A
Disable TBL Smoke Detector TROUBLE T
Class A TBL Smoke Detector TROUBLE T
Detailed Description: Used when only Smoke Detectors (both 2-wire and
4-wire) are connected to the circuit.
Figure 5-18. SMOKE Point Type
Pt. TYPE: EMERG Description: Combination Fire / Emergency
Circuit Status LCD Readout (2
nd
line) LED
Normal Monitor Zone NORMAL
Limited Monitor Zone SUPERVISORY S
Open Monitor Zone TROUBLE T
Short Monitor Zone ALARM A
Disable TBL Monitor Zone TROUBLE T
Class A TBL Monitor Zone TROUBLE T
Detailed Description: Used to connect two types of alarm devices on the same
zone. For example, nurse call type devices and fire alarm devices. The
emergency alarm devices (nurse call) will require the use of a current limiting
resistor. Emergency devices cause a supervisory service condition.
Figure 5-19. EMERG Point Type
Pt. TYPE: GENMON Description: Generator Monitor
(No Supervisory)
Circuit Status LCD Readout (2
nd
line) LED
Normal Generator Monitor OFF
Limited Generator Monitor OFF
Open Generator Monitor TROUBLE T
Short Generator Monitor SUPERVISORY S
Disable TBL Generator Monitor TROUBLE T
Class A TBL Generator Monitor TROUBLE T
Detailed Description: Used when Emergency generator monitoring is required.
The shorted condition of the circuit indicates an abnormal status and is
indicated by the Supervisory Service LED. The current limited condition of the
circuit will indicate generator is running in the alphanumeric display (if the
<ö> key is pressed) and can be tracked with an LED (must be programmed).
A current limiting resistor must be installed for this operation.
Figure 5-20. GENMON Point Type
Continued on next page
Point Type Messages for Monitor Points, Continued
Monitor Points (continued)
