2. Modify the settings as needed, using the information in the table below.
3. Click Apply/Save to commit your changes. The new interface appears on the DSL ATM Interface Configuration page.
4. To remove an interface, click the Remove checkbox next to it and then click the Remove button.
The fields on this page are defined below.
Field Name Description
VPI Enter a Virtual Path Identifier. A VPI is an 8-bit identifier that uniquely identifies a network path for ATM
cell packets to reach its destination. A unique VPI number is required for each ATM path. This setting
works with the VCI. Each individual DSL circuit must have a unique VPI/VCI combination. Options are 0-255.
The default is zero (0).
VCI Enter a Virtual Channel Identifier. A VCI is a 16-bit identifier for a unique channel. Options are 32-65535.
The default is 35.
Note: 1-31 are reserved for known protocols.
