Field Name Description
Ingress Interface Select an interface for incoming traffic. Options are LAN, WAN, Local, 2.4GHz, 5GHz, and any inter-
face defined for your network. The default is LAN.
Ether Type Select the Ethernet interface type for this classification. Options include IP, ARP, IPV6, PPPoE, and
any other Ethernet interface defined for your network.
Source MAC Address /
Mask
(Available for LAN, ATM, ETH, PPP-Routed and wireless interfaces only) Enter the source MAC
address and source MAC mask for this classification.
Destination MAC Address
/ Mask
(Available for LAN, ETH and wireless interfaces only) Enter the destination MAC address and des-
tination MAC mask for this classification.
Source IP Address [/
Mask] or Vendor Class ID
or User Class ID
(Available for WAN, ATM and PPP-Routed interfaces only) Select the source for this classification.
Options are:
l Source IP Address[/Mask]: Enter the source IP address and source IP mask.
l Vendor Class ID (DHCP Option 60): Enter the vendor class ID.
l User Class ID (DHCP Option 77): Enter the user class ID.
Destination IP Address
[/ Mask]
(Available for WAN and ATM interfaces only) Enter the destination IP address and source IP mask for
this classification.
IP Length Check
(Min/Max)
(Available for WAN, Local, ATM interfaces only) Enter the minimum and maximum number of digits
required for IP addresses.
Protocol (Available for WAN, Local, and ATM interfaces only)Select the protocol specified for this clas-
sification. Options are TCP, UDP, ICMP, and IGMP.
UDP/TCP Source Port (Appears when TCP or UDP is selected in the Protocol field) Enter the source port to be used for
this classification. You can enter a range (port:port) or a single port.
UDP/TCP Destination Port (Appears when TCP or UDP is selected in the Protocol field) Enter the destination port to be used
for this classification. You can enter a range (port:port) or a single port.
Specify Classification Results section
Specify Egress Interface Select an interface for outgoing traffic. Options include any interface defined for your network.
Specify Egress Queue Select from the available queues.
Note: Make sure to select a queue that is defined for the interface that you selected. If you select a
queue that is not defined for the selected interface, any packets classified into that queue are pro-
cessed by the default queue for the interface.
Mark 802.1p priority (Available for LAN, bridged and wireless interfaces only) This value is inserted into the Ethernet
frame and used to differentiate traffic. Lower values assign higher priorities. Options are 0 - 7.
Set Rate Limit (Kbps) Enter the data traffic rate limit for this classification in kilobits per second.
QoS Port Shaping
On this page, you can configure a fixed rate (Kbps) for each of the Ethernet ports.
