SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2018 26
Field Name Description
Select DSL Latency Select the level of DSL latency. Options are:
l Path0 (Fast): No error correction and can provide lower latency on error-free lines. This is
the default.
l Path1 (Interleaved): Error checking that provides error-free data which increases latency.
Select Scheduler for Queues
of Equal Precedence as the
Default Queue
Select the algorithm used to schedule queue behavior. VC scheduling is different than schedul-
ing done for default queues. Options are:
l Round Robin (weight=1): Packets are accessed in a round robin style and classes can be
assigned. Time slices are assigned to each process in equal portions and in circular order,
handling all processes without priority (also known as cyclic executive). This is the
default.
l Weighted Fair Queuing: Packets are assigned in a specific queue. This data packet
scheduling technique allows different scheduling priorities to be assigned to statistically
multiplexed data flows. Since each data flow has its own queue, an ill-behaved flow (that
sent larger packets or more packets per second than the others since it became active)
will only affect itself and not other sessions.
Default Queue Weight Enter the default weight of the specified queue. Options are 1-63. The default is 1.
Default Queue Precedence Enter the precedence of the specified group. The lower the value, the higher the priority.
Options are 1-8. The default is 8.
ETH Interface
On this page, you can configure ETH WAN interfaces. One of the four LAN ports on your gateway can be re-purposed to become an
RJ45 WAN port when needed.
Notes:
l Only one Ethernet WAN interface is allowed. If a WAN port it is already configured, you must remove it before you can
define a new one. Click the Remove checkbox and then click the Remove button. The Add button appears when the
existing port is removed.
l If a WAN port is already configured and associated with a WAN service, you must remove the WAN service configuration
before you can remove the port on this page.
