7. Modify the fields as needed, using the information in the table provided below.
Field Name Description
PPP Username Enter the username required for authentication to the PPP server.
PPP Password Enter the password required for authentication to the PPP server.
PPPoE Service Name (Optional) Enter a description for this service.
Authentication Method Select a means for authentication. Options are:
l AUTO: Attempt to automatically detect the handshake protocol (listed below).
l PAP: Password Authentication Protocol (plaintext passwords).
l CHAP: Challenge Handshake Authentication Protocol. (MD5 hashing scheme on pass-
words).
l MSCHAP: Microsoft Challenge Handshake Authentication Protocol. (Microsoft encryp-
ted password authentication protocol).
MTU [576-1492] Enter the MTU (Maximum Transmission Unit) size. Options are 576 - 1492 bytes. The default
is 1492 bytes.
Enable KeepAlive This option is enabled by default. To disable keepalive packets, clear the checkbox. Enter val-
ues in the following fields:
l LCP Echo Interval [1-60]: Enter the interval for sending echos in seconds. The
default is 30 seconds.
l LCP Echo Failure [1-100]: Enter the number of times that echos should be sent
before reporting echo failure. The default is 5 times.
Enable NAT This option is enabled by default. To disable NAT (Network Address Translation), clear the
checkbox.
Enable Fullcone NAT Click to enable "one-to-one" NAT. All requests from the same internal IPaddress and port are
mapped to the same external IP address and port. In addition, any external host can send a
packet to the internal host by sending a packet to the mapped external address.
Warning: Enabling this option will disable network acceleration and some security settings.
Enable MAC Clone Click to enable MAC cloning. Additional fields appear. Options are:
l Enter the MAC address that you want to clone.
l To use the MAC address of the connected PC, click Clone the PC MACAddress.
Enable Firewall This option is enabled by default. To disable the firewall, clear the checkbox.
Dial on Demand Click to enable dialing on-demand. The Inactivity Timeout (minutes) field appears. Enter the
of minutes before a session is timed out. Options are 1 - 4320. The default is zero (0).
When this option is enabled, connection automatically starts when there is outbound traffic
to the Internet. It automatically terminates if the connection is idle, based on the value in
the Idle Timeout setting.
PPP IP extension Click to forward all traffic to the specified DMZ IP. When you select this option, the NAT and
Firewall fields are hidden.
