1. In the left navigation menu, click Advanced Setup > VPN and then click Add. The following page appears.
2. Fill in the fields, using the information in the table below.
Field Name Description
Description Enter a useful description of this configuration.
WAN Interface Select the WAN interface for this client.
L2TP Server IP/Domain Enter the IP address of the L2TP server.
L2TP Username Enter the user name for the server.
L2TP Password Enter the password for the server.
Authentication Select the authentication method. Options are NOAUTH, AUTO, PAP, CHAP, MS-CHAP_V1, and
MS-CHAP_V2. The default is AUTO.
Enable MPPE (Optional) Click to enable Microsoft Point-to-Point Encryption.
MTU (Optional) Enter the maximum number of transmission units allowed for this client. Options are
576 - 1454. The default is 1454.
Enable NAT (Optional) Click to enable Network Address Translation features.
Enable Firewall (SPI) (Optional) Click to enable the firewall.
Enable Click to enable this L2TP client configuration.
