Chapter 3 Transport and Setting Up
3.3 Installation HRL Series
3-16
2. Hold the handle and pull up the front panel of the electrical unit, and remove it.
Fig. 3-8 Remove the front panel for the electrical unit
3. Loosen the power cable outlet cap and insert the power cable.
Fig. 3-9 Wiring of power supply cable
Handle
View A
power supply cable
Cap
Handle
