S2ODPF/S2ODP DIGITAL OUTPUT PGM CHANNEL
WITH & WITHOUT MASTER FADER VERSION 1
S2ODPF/S2ODP DIGITAL OUTPUT
PGM CHANNEL WITH & WITHOUT
MASTER FADER VERSION 1
Synchronisation Mode /
Sample Rate (kHz)
J3 J4 J5 J6
MASTER
32 Not Fitted Not Fitted Not Fitted Not Fitted
44.1 Fitted Not Fitted Not Fitted Not Fitted
48 Not Fitted Fitted Not Fitted Not Fitted
96 Fitted Not Fitted Fitted Not Fitted
AUTO
32 Not Fitted Fitted Fitted Not Fitted
44.1 Fitted Fitted Fitted Not Fitted
48 Not Fitted Not Fitted Not Fitted Fitted
96 Fitted Fitted Not Fitted Fitted
Auto Lock Not Fitted Not Fitted Fitted Fitted
Slave Mode Fitted Not Fitted Fitted Fitted
Reserved Not Fitted Fitted Fitted Fitted
Reserved Fitted Fitted Fitted Fitted
Output Bit Depth J7 J8
16 bits Not Fitted Not Fitted
20 bits Fitted Not Fitted
24 bits Not Fitted Fitted
Reserved Fitted Fitted
Channel Status Bits J9
Consumer Not Fitted
Professional Fitted
Sync Select
The pair of jumpers, J10 and J11, select the sync source between AES, pins 1 & 2, and
S/PDIF, pins 2 & 3. The default is AES/EBU. Both jumpers need to be altered for this to
work correctly.
Digital Output Mode
Jumper J12 selects the digital output mode between AES/EBU, pins 1 & 2, and S/PDIF,
pins 2 & 3. The default is AES/EBU.
Presets
Presets P1 & P2 are for altering the audio waveform symmetry (i.e. distortion) through the
VCA stage. They are factory set on nal test and should not be adjusted further.
Preset P3 sets the VCA fader gain to 0dB when the fader is fully open. This is preset on
nal test and should not require further adjustment, unless it has been found necessary to
replace the fader or other VCA components.
Presets, P5 (left) and P4 (right), set the peak digits through the conditioning circuits to
the analogue to digital converter. This is preset on nal test and should not require
further adjustment.
