S2 User Handbook
S2CSGE/S2CSG STEREO LINE AND
GRAM CHANNEL WITH & WITHOUT EQ
S2CSGE/S2CSG STEREO LINE AND
GRAM CHANNEL WITH & WITHOUT EQ
8
The connector pin-out is as follows;
Pin 1: Opto isolated Line 1 start NPN collector.
Pin 2: Common NPN emitter for Line 1 start and stop.
Pin 3: Opto isolated Line 1 stop NPN collector.
Pin 4: Opto isolated Gram input start NPN collector.
Pin 5: Common NPN emitter for Gram input start and stop.
Pin 6: Opto isolated Gram input stop NPN collector.
Pin 7: 0V logic.
Pin 8: General purpose I/O 1.
Pin 9: General purpose I/O 2.
Line 1 Left Input Connector
This XLR 3 pin socket is used for the left channel of input 1, and has the following
connections;
Pin 1: Screen.
Pin 2: Phase.
Pin 3: Non-phase.
Line 1 Right Input Connector
This XLR 3 pin socket is used for the right channel of input 1, and has the following
connections;
Pin 1: Screen.
Pin 2: Phase.
Pin 3: Non-phase.
Channel Options, Jumper Settings and Presets
The Stereo Line and Gram channel with and without EQ can be congured in a number of
dierent ways depending on the jumper options set on the board. The on-board processor’s
software is congured by jumpers J1 to J5 and channel identifying links. The Stereo Line and
Gram channel without EQ is identied by having links LK6 and LK11 tted. The Stereo Line
and Gram channel with EQ is identied by having links LK7 and LK11 tted. Other, customer
specic, options can be programmed into the software by special order. Special logic
options will be identied by having links LK9 and LK10 tted.
The standard options available are;
t 4FMFDUNPNFOUBSZPSMBUDIFETUBSUGPS*OQVU
t 4FMFDUNPNFOUBSZPSMBUDIFETUBSUGPS*OQVU
t &OBCMFDPOUJOVPVTNPNFOUBSZTUBSUGSPN0/CVUUPO
t &OBCMFPSEJTBCMF$VF1'-DBODFMGSPNGBEFS
t 4FMFDUUJNFSPQUJPO
t Bal/Pan Control Setup
