S2 User Handbook

POWER SUPPLY

The factory default is set to the new 1U S2-PSU. Should you be conguring the S2-PSUS

to work with a 2U S2-PSU, you have to modify the appropriate jumper/jumpers as shown

overleaf.

Fig 3-7: New S2-PSU Diagram.
