S2 User Handbook
117
17
S2ODAF/S2ODA DIGITAL OUTPUT AUD CHANNEL
WITH & WITHOUT MASTER FADER VERSION 2
S2ODAF/S2ODA DIGITAL OUTPUT
AUD CHANNEL WITH & WITHOUT
MASTER FADER VERSION 2
Pin 1: Screen.
Pin 2: Phase.
Pin 3: Non-phase.
Channel Options, Jumper Settings and Presets
The AUD digital stereo output channel can be congured in a number of dierent ways
depending on the jumper options set on the board. The on-board processor’s software
is congured by jumpers J3 to J9 and channel identifying links. The AUD digital output
channel is identied by having links LK43 and LK45 tted. The AUD digital output with fader
is identied by having links LK43, LK45 and LK46 tted.
The standard options available are;
t 4FMFDUNPEFBOETBNQMFSBUF
t 4FMFDUDIBOOFMTUBUVTCJUT
t 4FMFDU"&4PS41%*'PVUQVU
t 4FMFDU"&4PS41%*'TZODJOQVU
Summary of Jumper Settings for the AUD Digital Output Channel
Jumper
Set over
Pins
Eect
J1 Not Fitted
J2 Not Fitted
J3-J6 See table (page 116) Synchronisation Mode & Sample Rate Selection.
J7-J8 Reserved.
J9 See table (page 116) Channel Status Bits Selection.
J10
1 & 2
2 & 3
AES/EBU sync input selected.
S/PDIF sync input selected.
J11 1 & 2 AES/EBU sync input selected.
2 & 3 S/PDIF sync input selected.
J12 1 & 2 S/PDIF output selected.
2 & 3 AES/EBU output selected.
J13
1&2
None
Reserved.
Reserved.
Note: Options in bold are set as default when shipped.
