S2 User Handbook
6
S2CMM MIC/MIC CHANNEL WITH EQ
S2CMM MIC/MIC CHANNEL WITH EQ
The connector pin-out is as follows;
Pin 1: Opto isolated mic 1 cue light NPN collector.
Pin 2: Common NPN emitter for above.
Pin 3: No connection.
Pin 4: Opto isolated mic 2 cue light NPN collector.
Pin 5: Common NPN emitter for above.
Pin 6: No connection.
Pin 7: 0V logic.
Pin 8: Cough/reverse talkback switch (make to 0V to activate).
Pin 9: Talkback mic enable (make to 0V to enable the mic input as the T/B mic).
Insert Send Connector
This XLR 3 pin plug is a balanced line level pre-EQ output intended to be fed to an eects
processor for the microphone input, and has the following connections;
Pin 1: Screen.
Pin 2: Phase.
Pin 3: Non-phase.
Insert Return Connector
This XLR 3 pin socket is intended for the input signal from the equipment fed by the Insert
Send. The connections are the same as the Insert Send connector.
Channel Options, Jumper Settings and Presets
The Mic/Mic channel can be congured in a number of dierent ways depending on the
jumper options set on the board. The on-board processor’s software is congured by
jumpers J1 to J4 and channel identifying links. The Mic/Mic channel is identied by having
links LK16 and LK17 tted. Other, customer specic, options can be programmed into the
software by special order. Special logic options will be identied by having links LK23 and
LK24 tted.
The standard options available are;
t 6TJOHBQIBOUPNQPXFSFENJDSPQIPOF
t &OBCMFGVMM-'SFTQPOTFPONJDSPQIPOFJOQVUT
t &OBCMFUIF*OTFSU1PJOU
t 4FMFDUNPNFOUBSZPS$VF-JHIU
t 4FMFDUNPOJUPSNVUFGPSTUVEJPPSDPOUSPMSPPN
t &OBCMFPSEJTBCMF$VF1'-DBODFMGSPNGBEFS
t 5BMLCBDLJOQVUTFMFDUJPO
