The connector pin-out is as follows;
Pin 1: Opto isolated Line 1 start NPN collector.
Pin 2: Common NPN emitter for Line 1 start and stop.
Pin 3: Opto isolated Line 1 stop NPN collector.
Pin 4: Opto isolated Line 2 start NPN collector.
Pin 5: Common NPN emitter for Line 2 start and stop.
Pin 6: Opto isolated Line 2 stop NPN collector.
Pin 7: 0V logic.
Pin 8: General purpose I/O 1.
Pin 9: General purpose I/O 2.
Line 1 Left Input Connector
This XLR 3 pin socket is used for the left analogue channel of input 1, and has the following
connections;
Pin 1: Screen.
Pin 2: Phase.
Pin 3: Non-phase.
Line 1 Right Input Connector
This XLR 3 pin socket is used for the right analogue channel of input 1, and has the following
connections;
Pin 1: Screen.
Pin 2: Phase.
Pin 3: Non-phase.
Channel Options, Jumper Settings and Presets
The dual stereo channel with and without EQ can be congured in a number of dierent
ways depending on the jumper options set on the board. The on board processors software
is congured by jumpers J1 to J5 and channel identifying links. The dual stereo channel
without EQ is identied by having links LK4 and LK11 tted. The dual stereo channel with
EQ is identied by having links LK5 and LK11 tted. Other, customer specic, options can be
programmed into the software by special order. Special logic options will be identied by
having links LK9 and LK10 tted.
The standard options available are;
t 4FMFDUNPNFOUBSZPSMBUDIFETUBSUGPS*OQVU
t 4FMFDUNPNFOUBSZPSMBUDIFETUBSUGPS*OQVU
t &OBCMFDPOUJOVPVTNPNFOUBSZTUBSUGSPN0/CVUUPO
t &OBCMFPSEJTBCMF$VF1'-DBODFMGSPNGBEFS
t 4FMFDUUJNFSPQUJPO
t #BM1BO$POUSPM4FUVQ
