20 Meterbridge Modules
The meterbridge area can house dierent styles of metering, dual timer, PFL/Talkback
speaker, switcher and talkback modules. S2’s meterbridge modules are freely assignable so
that you can position them exactly where you want them.
Meterbridge Module Types
Three styles of dual meter panels, for displaying signal levels, are available for mounting in
the meterbridge: Dual VU panel S2-MVU, dual PPM panel S2-MPPM, and dual true PPM
panel S2-MPPT*. The S2-ML53 is an LED meter for displaying both VU and PPM scales.
Illuminated LEDs on each meter panel indicate the monitoring source.
A meterbridge panel, S2-MPH can be linked to a dual meter panel and used to display
phase information on the selected source.
A meterbridge loudspeaker panel, S2-ML, can be used to monitor PFL and Reverse Talkback
via separate level controls. The speaker will mute in a “mic live” situation.
A comprehensive dual timer display, S2-MT, is available for timing events triggered from
mic or line input modules. The timer can also display the real time and date synchronised to
a standard time broadcast.
Two talkback panels are available. The S2-MTB6 can be used for communicating with up to
6 other mixers or dedicated talkback systems, and the S2-MTBS is used for interfacing with
a Sonifex Station Master.
One, or two source select panels, S2-M6SS, can be used to expand the number of input
sources monitored using the EXT 1 and EXT2 buttons (6 for each), as well as a general input
source selector for other applications.
A 1 button switch panel, S2-MSB1, and 3 button switch panel, S2-MSB3, are 1 channel
wide meterbridge panels, with 1 and 3 buttons respectively which can be used for bespoke
control of the S2, or for your own purposes, e.g. for equipment control.
