Rear Panel

It is important to connect the mains supply in accordance with the information given.

Ensure that the rear panel mains voltage statement on the separate power supply indicates

that your equipment is suitable for your mains supply voltage and that the mains supply

fuse is correctly rated. The fuse as supplied is correct for the voltage setting.

The power cable supplied carries an EARTH conductor, which is connected internally to the

equipment chassis ground. This connection through a properly wired power Connector

is essential for safe operation. Disconnection of this earth connection may render the

Equipment unsafe, with a consequential possible electrical shock hazard from exposed

metallic parts.

Safety of Mains Operated Equipment

This equipment has been designed to meet the safety regulations currently advised

in the country of purchase and it conforms to the safety regulations specied by

use of the CE Mark.

This equipment will operate in a horizontal position.

WARNING: The power must be switched o at the supply or the power lead must be

disconnected before attempting to remove the panels or cover. Removal of the panels

and cover can expose dangerous voltages. The cover is connected to the chassis ground

of the equipment by means of xing screws. It is essential to maintain this earth-ground

connection to maintain a safe operating environment.

In addition, to provide an Electromagnetic Shield, contact between the cover and the

chassis must be maintained when in use.

The power supply is switchable between 230V & 115V.

Warning: There are no user serviceably parts inside the machine. If you should ever

need to look inside the unit, always disconnect the mains supply before removing the

equipment covers.

The rear panel of the equipment carries the Serial Number of the machine. The operating

voltage of the S2 power supply is selectable at the fuse carrier on the power inlet port of the

S2-PSU unit. Ensure that the machine operating voltage is correct for your mains

power supply.

POWER SUPPLY
